PVDC Casing

Applications

PVDC casing is a high barrier film used to package retort sausage and cheese. It is currently recognized as the plastic packaging material with excellent comprehensive performance in terms of barrier properties. It has oil resistance, taste retention, excellent moisture resistance properties, and also has excellent printing performance.

  1. Thickness: 40 micron – 50 micron
  2. Width range: 20mm – 1200mm
  3. Color: red, orange, gold, yellow, white, brown, black, transparent, etc.
  4. Type: unprinted film, surface pinting, inner printing

Product Details

PVDC casing is a high barrier film used to package retort sausage and cheese. It is currently recognized as the plastic packaging material with excellent comprehensive performance in terms of barrier properties. It has oil resistance, taste retention, excellent moisture resistance properties, and also has excellent printing performance.

  1. Thickness: 40 micron – 50 micron
  2. Width range: 20mm – 1200mm
  3. Color: red, orange, gold, yellow, white, brown, black, transparent, etc.
  4. Type: unprinted film, surface printing, inner printing

Features:

  • It runs smoothly on KAP, CAP or ZAP line
  • The casing utilization rate is high
  • The barrier performance is excellent, and the shelf life of retort sausage is guaranteed
  • The thickness is uniform, the shrinkage rate is stable, and the retort sausage output rate is high
  •  The breakage rate after cooking is low. It can reduce the production cost
  • Good adaptability, suitable for different meat formulas



Specifications




ItemUnitLimit ValueTypical Value
Thicknessμm40~5042
Tensile Strength
(MD/TD)
MPa≥60/8084/105
Elongation at break
(MD/TD)
%≥50/4080/66
Tear Load
(MD/TD)
N≥0.2/0.20.35/0.27
Shrinkage Rate
(MD/TD)
% -15~-30/ -15~-30-27/-19
WVTRg/(㎡·24h)
38℃,90%RH
≤51.7
OTRcm³/(㎡·24h·0.1MPa)
23℃,50%RH
≤2517.8
